Insulated operating rod, high-voltage brake lever (also known as insulated operating rod, insulated rod, high-voltage operating rod, common name multi-purpose lingke rod) according to the voltage level can be divided into 10KV, 35KV, 110KV, 220KV, 330KV, 500KV
Features
The insulating operating lever is an insulating tool used to operate live equipment in a short time, such as turning on or off high-voltage isolation switches, dropping fuses, etc.
1. The interface type insulated operating rod is a more commonly used insulating rod.The section adopts a spiral interface, which can be up to 10 meters long, and can be divided into bags for easy carrying.
2. The telescopic high-pressure lingke rod has a 3-section telescopic design, which is generally 6 meters long, light weight, small size, easy to carry, and easy to use. It can be retracted and positioned to any length according to the space used, which effectively overcomes the inconvenience of the interface Lingke rod due to its fixed length. Disadvantages of inconvenience in use.
3. The interface of the free-blade high-pressure lingke rod adopts a free-blade design, which will not reverse after tightening.
Basic parameters
1． Insulated operating rods can be divided into: 3 meters, 4 meters, 5 meters, 6 meters, 8 meters, and 10 meters according to their length
2． Insulated operating rods can be divided into: 10KV, 35KV, 110KV, 220KV, 330KV, 500KV according to voltage level
3．The material of the insulating operating rod: The insulating operating rod is generally made of glass fiber reinforced plastic epoxy resin rod, which is hand-rolled into a shaped rod and a mechanical pultrusion forming rod.The two kinds of insulating rods have their own advantages: the advantage of manual rolling rods is that they have high tensile strength, but the longitudinal strength is relatively small compared to the pultruded rods.The advantage of the pultrusion rod of the electroscope mechanism is that it has high strength, but the lateral tensioning is smaller than that of the manual winding rod.
4．The color of the insulating operating lever: The buckle-type insulating operating lever generally adopts the yellow insulating lever, and the telescopic insulating operating lever generally adopts the upper red and lower yellow color treatment, and the red color is non-slip treatment.The rod is yellow after it is pulled apart
